Hikvision

Specifications

High-Quality Imaging With 2 MP, 1920 × 1080 Resolution

24/7 Color Imaging With F1.0 Aperture

Camera

Image Sensor: 2 MP Cmos

Max. Resolution:1920 (H) × 1080 (V)

Min. Illumination: 0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR

Shutter Time: PAL: 1/12.5 s to 1/50,000 s, NTSC: 1/15 s to 1/50, 000 s

Day & Night: ICR

Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360°

Signal System: PAL/NTSC

Lens

Lens Type: 2.8 mm, 3.6 mm fixed Lens

Focal Length & FOV

2.8 mm, Horizontal FOV: 105°, Vertical FOV: 59°, Diagonal FOV: 127°

3.6 mm, Horizontal FOV: 87°, Vertical FOV: 46°, Diagonal FOV: 105°

Lens Mount: M12

Microphone

Pickup Distance: In A Radius Of Up To 5 m

Amount: 1

Illuminator

Supplement Light Type: Smart, IR, White Light

Supplement Light Range: IR: Up to 25 m


Image Settings: Brightness, Sharpness, Smart IR

Frame Rate

TVI: 1080P @ 30 fps, 1080P @ 25 fps

AHD: 1080P @ 30 fps, 1080P @ 25 fps

CVI: 1080P @ 30 fps, 1080P @ 25 fps

CVBS: PAL/NTSC

Day / Night Mode: Auto /Color

Wide Dynamic Range: Digital WDR

Image Enhancement

DWDR/BLC/HLC/Global

White Balance: Auto/Manual

Audio

Audio Function: Echo Cancellation, AI Noise Reduction, Automatic Gain Control

Interface

Video Output: 1 HD Analog Output

General

Power: 12 VDC ± 25%, max.5.7 W

*You Are Recommended To use One Power Adapter To Supply The Power For One Camera*

Material: Plastic

Dimension: 179 mm × 66 mm × 69.1 mm (7.05" × 2.6" × 2.72")

Weight: Approx. 245 g (0.54 lb.)

Operating Condition

-40 °C to 60 °C (-40 °F to 140 °F)

Humidity 90% Or Less (Non-Condensing)

Communication: HIKVISION-C

Language: English

Approval

Protection

IP67
