This 200m HDMI KVM IP Extender allows you to transmit high-definition video, audio, and USB keyboard/mouse signals over long distances using a single CAT5e, CAT6, CAT6a or CAT7 network cable. Designed for professional and home use, it supports point-to-point, one-to-many, and cascade connection modes, making it ideal for digital signage, control rooms, classrooms, boardrooms, retail displays, and remote workstation setups.

Supporting resolutions up to 1080p and compliant with HD 1.3 standards, the extender ensures clear, stable video output. Using standard TCP/IP transmission, one transmitter (TX) can connect to up to 20 receivers (RX) when used with a network switch, allowing flexible multi-display distribution across long distances up to 200 meters.

The extender includes full USB KVM functionality, allowing remote operation of a connected PC or media player using a USB keyboard and mouse. It also supports IR remote control passthrough, allowing you to control your source device from the receiving end. With pure hardware design, the system is completely plug-and-play with no software required.

Key features

• Extends HDMI audio/video up to 200m over a single CAT5e/6/6a/7 cable
• Supports 1080p, 720p, and 480p HD resolutions
• USB keyboard and mouse extension for remote PC control
• IR remote control passthrough for controlling source devices remotely
• Supports point-to-point, one-to-many, and cascading modes
• One transmitter can connect to up to 20 receivers via a network switch
• TCP/IP transmission and 802.3 Ethernet standard
• Pure hardware design, plug-and-play with no drivers required
• Ideal for offices, classrooms, digital signage, control centers, retail displays, and long-distance HDMI connections

Specifications

• Transmission distance: Up to 200m
• Video resolutions: 1080p, 720p, 480p
• HD version: HD 1.3
• Audio sample rate: 32kHz, 44.1kHz, 48kHz
• IR control frequency: 38KHz
• Power supply: DC 5V/1A
• Package weight: 1384g
• Package dimensions: 22 × 18 × 8 cm
• Package contents: 1 × transmitter, 1 × receiver, 2 × power adapters, 2 × IR cables, 1 × user guide
