Hikvision

Specifications

Video & Audio Input

8 Channels Via BNC Interface Supporting HDTVI, AHD, CVI, CVBS, and IP Inputs

Supports Up To 10 Total Channels Including Up To 2-Ch (Or Up To 10-Ch Via IP) With Up To 5 MP Resolution

Audio Is Supported Via Coaxial Cable

Video Compression: H.265 Pro+, H.265 Pro, H.265, and H.264 / H.264+

Encoding Resolution: Up To 1080p Lite @ 15 fps / 720p

Hard Drive Storage: 1 SATA Interface Supporting Up To 4 TB Capacity

Network & Ports: 1 RJ45 10/100 Mbps Self-Adaptive Ethernet Interface, 2 USB 2.0 Ports

And Simultaneous HDMI / VGA Outputs (Up To 1920 × 1080 Resolution)

Smart Features: Deep Learning-Based Human And Vehicle Target Classification For Motion Detection 2.0 To Reduce False Alarms

Dimensions & Weight: 200 × 200 × 48 mm (7.9 × 7.9 × 1.9 Inches); = 1 kg Without A Hard Drive

Total Bandwidth:72 Mbps

Remote Connection: 64

Network Protocol: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, Stupp, UPnP, HTTPS

Network Interface: 1, RJ45 10/100 Mbps Self-Adaptive Ethernet Interface

Auxiliary Interface

SATA: 1 SATA Interface

Capacity: Up to 4 TB Capacity For Each Disk

USB Interface: Rear Panel: 2 × USB 2.0

Alarm In / Out: N/A

General

Power Supply: 12 VDC, 1.5 A

Consumption: = 17 W (without HDD)

Working Temperature: -10 °C to 55 °C (14 °F to +31 °F)

Working Humidity: 10% to 90%

Dimension (W × D × H): 200 × 200 × 48 mm (7.9 × 7.9 × 1.9 Inch) 1 kg (Without HDD, 2.2 lb.)
