AMD Ryzen 5 7600 5nm Socket AM5 6 Core 3.8GHz up to 5.1GHz 32MB L3 Cache Processor

Overview:

Powerful Gaming Starts Here
This overclockable processor is built for intense gaming, and comes bundled with a low-profile AMD Wraith Stealth cooler.

Specifications:

Product Code	100-100001015BOX
General Specifications
Platform	Desktop
Market Segment	Enthusiast Desktop
Product Family	AMD Ryzen Processors
Product Line	AMD Ryzen 5 Processors
AMD PRO Technologies	No
Consumer Use	Yes
Regional Availability	Global
Former Codename	"Raphael AM5"
Architecture	"Zen 4"
# of CPU Cores	6
Multithreading (SMT)	Yes
# of Threads	12
Max. Boost Clock	Up to 5.1GHz
Base Clock	3.8GHz
L1 Cache	384KB
L2 Cache	6MB
L3 Cache	32MB
Default TDP	65W
Processor Technology for CPU Cores	TSMC 5nm FinFET
Processor Technology for I/O Die	TSMC 6nm FinFET
CPU Compute Die (CCD) Size	71mm²
I/O Die (IOD) Size	122mm²
Package Die Count	2
Unlocked for Overclocking	Yes
AMD EXPO Memory Overclocking Technology	Yes
Precision Boost Overdrive	Yes
Curve Optimizer Voltage Offsets	Yes
AMD Ryzen Master Support	Yes
CPU Socket	AM5
Supporting Chipsets	X670E
	X670
	B650E
	B650
CPU Boost Technology	Precision Boost 2
Instruction Set	x86-64
Supported Extensions	AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Thermal Solution (PIB)	AMD Wraith Stealth
Max. Operating Temperature (Tjmax)	95°C
Launch Date	1/14/2023
*OS Support	Windows 11 - 64-Bit Edition
	Windows 10 - 64-Bit Edition
	RHEL x86 64-Bit
	Ubuntu x86 64-Bit
	*Operating System (OS) support will vary by manufacturer.
Connectivity
USB Type-C Support	Yes
Native USB 3.2 Gen 2 (10Gbps) Ports	4
Native USB 3.2 Gen 1 (5Gbps) Ports	0
Native USB 2.0 (480Mbps) Ports	1
Native SATA Ports	0
PCI Express Version	PCIe 5.0
Native PCIe Lanes (Total/Usable)	28/24
Additional Usable PCIe Lanes from Motherboard	AMD X670E
	12x Gen4
	AMD X670
	12x Gen4
	AMD B650E
	8x Gen4
	AMD B650
	8x Gen4
NVMe Support	Boot, RAID0, RAID1, RAID10
System Memory Type	DDR5
Memory Channels	2
Max. Memory	128GB
System Memory Subtype	UDIMM
Max Memory Speed	2x1R
	DDR5-5200
	2x2R
	DDR5-5200
	4x1R
	DDR5-3600
	4x2R
	DDR5-3600
ECC Support	Yes (Requires mobo support)
Graphics Capabilities
Integrated Graphics	Yes
Graphics Model	AMD Radeon Graphics
Graphics Core Count	2
Graphics Frequency	2200 MHz
GPU Base	400 MHz
USB Type-C DisplayPort Alternate Mode	Yes
Product IDs
Product ID Boxed	100-100001015BOX
Product ID Tray	100-000001015
Key Features
Supported Technologies	AMD EXPO Technology
	AMD Ryzen Technologies
