Sharp, slim, and effortless. The AOC 22B30HM2 is a 21.5-inch VA panel monitor delivering vivid color, deep contrast, and smooth 100Hz refresh via HDMI for work and play.

Key Features

• 21.45" VA panel with Full HD 1920 × 1080 resolution
• Smooth refresh: 100Hz over HDMI; 75Hz over VGA
• Fast response: 4ms GtG / 1ms MPRT
• High contrast: 3000:1 (typical) with rich blacks
• Wide viewing angles: 178° (H) / 178° (V)
• Wide color: NTSC 86% (CIE1976) / sRGB 102% (CIE1931)
• VESA 100 × 100 mm wall-mount compatible
• Tilt-adjustable stand: -5° to 23°

Technical Specifications

• Model name: 22B30HM2
• Panel: 21.45" VA
• Pixel pitch: 0.2493 (H) × 0.241 (V) mm
• Effective viewing area: 478.66 (H) × 260.28 (V) mm
• Brightness (typical): 250 cd/m²
• Contrast ratio: 3000:1 (typical); 20,000,000:1 (DCR)
• Response time: 4ms GtG / 1ms MPRT
• Color gamut: NTSC 86% (CIE1976) / sRGB 102% (CIE1931)
• Optimal resolution & refresh:
  • 1920 × 1080 @ 100Hz (HDMI)
  • 1920 × 1080 @ 75Hz (VGA)
• Display colors: 16.7 million
• Inputs: 1 × HDMI 1.4, 1 × VGA
• HDCP: HDMI 1.4
• USB hub: No
• Speakers: No
• Audio line-in/earphone: No
• Power supply: External 19VDC, 1.31A
• Power consumption (typical): 17W
• Stand adjustment: Tilt -5° to 23°
• VESA mount: 100 × 100 mm
• Cabinet color: Black

Dimensions & Weight

• Without stand (mm): 284.8 (H) × 493.8 (W) × 35.8 (D)
• With stand (mm): 379.1 (H) × 493.8 (W) × 169.9 (D)
• Packaging (mm): 350 (H) × 565 (W) × 93 (D)
• Weight without stand: 1.79 kg
• Weight with stand: 2.02 kg
• Weight with packaging: 3.49 kg

Compliance & In the Box

• Regulatory approvals: CE, BSMI, RCM, MEPS, RoHS
• Included: 1 × HDMI cable (1.8 m)
• Warranty: 3 years

Note: Actual refresh rate and performance depend on GPU/port capabilities and cable quality. Specifications may change without prior notice.
