| Model |
4G-AX56 |
| Network Standard |
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
|
| Product Segment |
AX1800 ultimate AX performance |
| WiFi Data Rate
|
802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps
|
| Connectivity Technology |
LTE: Downlink 300 Mbps / Uplink 50 Mbps
HSPA+: Downlink 42 Mbps / Uplink 11 Mbps
4G FDD-LTE: 1 /3 /5 /7 /8 /20 /28
4G TDD-LTE: 38 /40 /41
3G UMTS: 1 /3 /5 /8
|
| Antenna |
WiFi: 2 x external fixed antenna
LTE: 1 x external fixed antenna, 1 x internal antenna
|
| Memory |
128 MB Flash
512 MB RAM
|
| Operating Frequency |
2.4 GHz / 5 GHz |
| Operating Mode |
Modem Router,Access Point |
| I/O Ports |
1 x Gigabit WAN port, 4 x Gigabit LAN ports, 1 x Nano SIM tray slot |
| Buttons |
Power, Reset, WPS
|
| LED Indicator
|
Power x 1
WiFi x 2
WAN x 1
Mobile WAN connection x 1
Mobile WAN signal x 3
|
| Package Content |
4G-AX56
Quick Start Guide
Warranty Card
RJ45 Cable
Power Adapter
|
| Product Weight (g) |
513 |
| Product Dimensions |
242 x 100 x 325 |
| Parental Control |
"Allow you to block access to unwanted websites and apps."
Customized Internet Schedule
|
| Guest Network |
Support Guest Network
Guest Network Connection Time Limit
|
| Security |
WPA/WAP2-Enterprise,WPA/WPA2-Personal,WPA2-Enterprise,WPA2-Personal,WPA2/WPA3-Personal,WPA3-Persona
WPS
SSH
Firewall
32
64
|
| AiProtection |
AiProtection Classic
Router Security Assessment
Malicious Site Blocking |
| VPN |
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Server Open VPN
VPN Server PPTP
|
| Traffic Control |
Bandwidth Limiter
Traditional QoS
Real-time traffic monitor
Wired Traffic Monitor
|
| WAN |
Internet Connection Type : Mobile WAN, Ethernet WAN
Dual WAN
Port Forwarding
DMZ
DDNS
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE relay
|
| LAN |
DHCP Server
IGMP Snooping
IPTV
Manually Assign IP Address
Maximum Manually Assign IP Address Rule : 64
Wake on LAN (WOL)
|
| Wireless |
MU-MIMO
UTF-8 SSID
WiFi MAC Address Filter
Wireless Scheduler
Airtime Fairness
Universal Beamforming
Explicit Beamforming
|
| User Interface |
WEB: ASUSWRT
APP: ASUS Router APP
|
| Administration |
SMS Message
Configuration Backup and Restore
Diagnosis Tools
Feedback System
System Log
|
|
|
|
|
|
|
|
|
|
|
|
|
