Cooler Master MasterBox Lite 301 Micro ATX Tempered Glass Case, 4 Expansion slots, 1x 3.5" Drive bays, 1x 2.5" Drive bays, I/O panel - 1x USB 3.2 Gen 1 Type-A / 1x USB 3.2 Gen 1 Type-C / 1x 3.5mm Combo, 163.5mm clearance CPU Cooler, 160mm clearance PSU, 365mm clearance Graphics, 18.5mm cable routing

Overview:

Effortless Efficiency Elite 301 Lite
High in value and attention to detail, Cooler Master's Elite 301 lite offers users a cost effective, space conscious solution to gaming and computing needs.

Elite 301 features a large intake grill to ensure a smooth, and efficient running system. The fully black coating and included PSU cover allows for clean builds that are visually appealing as well as functional.

Features:

Tool-less Intake Panel
Constructed with a substantially large, unrestricted intake grill to ensure that the system runs cool and efficiently. The front panel could be easily removed by magnets, making it easier for daily maintenance.

Versatile Cooling Options
Supports up to six fans and 280mm radiator to ensure that performance is not compromised.

Large Support, Minimized Footprint
Despite its compact size, Elite 301 lite supports up to 365mm graphics cards, 163.5mm CPU Coolers, providing solid potential for future upgrades.

Breathable Power Supply Shroud
The PSU cover is ventilated on top of the power supply location, allowing actively cooled units to be installed in multiple orientations, while maintaining support for passively cooled power supplies.

USB Type-C Support
USB Type C port built into the I/O panel allows multi-purpose, streamlined data transmission.

Specifications:

Product Code	E301L-KGNN-S00
Model Number	E301L-KGNN-S00
Exterior Color	Black
Materials	Steel, Plastic, Tempered Glass (Left Side Panel)
Dimensions (L x W x H)	390 x 203.5 x 430mm incl protrusions / 377 x 203.5 x 410mm excl protrusions
Volume	34.13L (incl. Protrusions)
Motherboard Support	ITX / Micro ATX
Expansion Slots	4
3.5" Drive Bays	1
2.5" Drive Bays	1 (Max. 2)
I/O Panel	1x USB 3.2 Gen 1 Type-A
I/O Panel	1x USB 3.2 Gen 1 Type-C
I/O Panel - Audio In / Out	1x 3.5mm Combo
Pre-installed Fans - Rear	1x 120mm Black Fan
Fan Support - Front	3x 120mm
Fan Support - Top	2x 120mm / 2x 140mm
Fan Support - Rear	1 x 120mm
Radiator Support - Front	120 / 240mm
Radiator Support - Top	120 / 140 / 240 / 280mm
Radiator Support - Rear	120mm
Clearance - CPU Cooler	163.5mm
Clearance - PSU	160mm
Clearance - GFX	365mm (without front fans & radiator)
Cable Routing	18.5mm
Dust Filters	Top / Bottom / Front
Power Supply Support	ATX
Series	Elite Series
Size	Mini Tower
