Dahua 5MP HDCVI fixed IR Eyeball Analogue Camera with 2.8mm fixed Lens, 1/2.7" CMOS image sensor, 2880x1620 Maximum Resolution, Progressive scanning system, 20 m IR distance, M12 Mount Type, Video Output choices of CVI / TVI / AHD / CVBS by one BNC Port, BLC / HLC / DWDR, DWDR, AGC gain control, 2D noise reduction

Overview:

HAC-T1A51
5MP HDCVI Fixed IR Eyeball Camera

• Max. 25 fps@5MP (16:9 video output)
• CVI/CVBS/AHD/TVI switchable
• 3.6 mm fixed lens (2.8 mm optional)
• Max. IR length 20 m, Smart IR
• DC12V

Specifications:

Product Code	DH-HAC-T1A51P-0280B-S2
Camera
Image Sensor	1/2.7" CMOS
Max. Resolution	2880 (H) x 1620 (V)
Pixel	5MP
Scanning System	Progressive
Electronic Shutter Speed	PAL: 1/25-1/100000 s
	NTSC: 1/30-1/100000 s
Min. Illumination	0.02 Lux/F2.0, 30IRE, 0 Lux IR on
S/N Ratio	More than 65 dB
Illumination Distance	20 m (66 feet)
Illuminator On/Off Control	Auto, manual
Lens
Lens Type	Fixed lens / Fixed iris
Mount Type	M12
Focal Length	3.6mm (2.8mm Optional)
Max Aperture	F2.0
Angle of View	2.8 mm: 125° x 106° x 56°
	(diagonal x horizontal x vertical)
	3.6 mm: 104° x 88° x 46°
	(diagonal x horizontal x vertical)
Focus Control	N/A
Close Focus Distance	2.8 mm: 0.8 m (2.6 ft)
	3.6 mm: 1.2 m (3.9 ft)
Pan / Tilt / Rotation
Pan/Tilt/Rotation	Pan: 0° - 360°
	Tilt: 0° - 78°
	Rotation: 0° - 360°
Video
Resolution	5M (2880 x 1620), 4M (2560 x 1440)
	1080P (1920 x 1080), 960H (960 x 576/960 x 480)
Frame Rate	CVI:
	PAL:5M@25 fps, 4M@25 fps, 1080P@25 fps
	NTSC:5M@25 fps, 4M@30 fps, 1080P@30 fps
	AHD:
	PAL:4M@25 fps
	NTSC:4M@30 fps
	TVI:
	PAL:4M@25 fps
	NTSC:4M@30 fps
	CVBS:
	960H
Video Output	Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Day/Night	Auto (ICR) / Manual
OSD Menu	Multi-language
BLC Mode	BLC / HLC / DWDR
WDR	DWDR
Gain Control	AGC
Noise Reduction	2D
White Balance	Auto, manual
Smart IR	Yes
Mirror	Off/On
Privacy Masking	Off / On (8 area, rectangle)
Certifications
Certifications	CE (EN55032, EN55024, EN50130-4, EN60950-1
	EN 62368-1:2014+A11:2017)
	FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
Interface
Audio Interface	N/A
Eelectrical
Power Supply	12V DC ±30%
Power Consumption	Max. 2.7W (12V DC, IR on)
Environmental
Operating Conditions	-40°C to +55°C (-40°F to +131°F) /Less than 95% RH
	*Start up should be done at above -40°C (-40°F)
Storage Conditions	-40°C to +55°C (-40°F to +131°F) /Less than 95% RH
Ingress Protection & Vandal Resistance	NA
Construction
Casing	Plastic
Dimensions	Ø85.4 mm x 68.8 mm (Ø3.36 x 2.71")
Net Weight	0.09 kg (0.20 lb)
Gross Weight	0.14 kg (0.31 lb)
