Description

Key Features and Benefits

1. High Charging and Discharging Capacity: The inverter can handle a maximum charging and discharging current of 190A, ensuring quick and efficient energy transfer. This capacity supports a stable and reliable power supply, accommodating high energy demands without compromising performance.
2. Scalability: One of the standout features of the SUN-7.6K/8K-SG01LP1-EU is its ability to connect up to 16 units in parallel. This feature is applicable for both on-grid and off-grid operations, making it highly scalable and adaptable to growing energy needs. Whether it’s a residential setup or a larger commercial installation, this inverter can expand as your energy requirements increase.
3. Diverse Battery Compatibility: The inverter is compatible with both lead-acid and lithium-ion batteries. It automatically adapts to the battery management system (BMS), which optimizes the charging strategy to enhance battery performance and lifespan. This compatibility provides great flexibility in choosing or upgrading battery systems.
4. AC Coupling: The inverter supports AC coupling, making it easy to retrofit existing solar power systems. This feature allows the integration of the hybrid inverter into current setups without significant modifications, providing an efficient upgrade path for enhancing energy storage capabilities.
5. User-Friendly Interface: Equipped with a colorful touch LCD display, the inverter offers a user-friendly interface that simplifies monitoring and control. The display provides real-time data on energy production, consumption, and storage, making energy management straightforward and accessible.
6. Robust Protection and Safety Features: The Deye SUN-7.6K/8K-SG01LP1-EU is designed with comprehensive protection mechanisms. These include DC polarity reverse connection protection, AC output overcurrent protection, thermal protection, ground fault current monitoring, and more. These features ensure safe and reliable operation under various conditions.
7. High Efficiency: With a maximum efficiency of 97.6%, a Euro Efficiency of 96.5%, and MPPT (Maximum Power Point Tracking) efficiency greater than 99%, the inverter maximizes the use of available solar energy. This high-efficiency rate contributes to lower energy losses and higher overall system performance.
8. Environmental Compatibility: The inverter is built to withstand harsh environmental conditions, operating in temperatures ranging from -40 to +60°C with derating above 45°C. It is also rated for operation at altitudes up to 2000 meters, making it suitable for a wide range of geographical locations.
9. Communication and Monitoring: It supports multiple monitoring modes, including GPRS, WIFI, Bluetooth, 4G, and LAN (optional). The communication interfaces include RS485, RS232, and CAN, providing versatile options for remote monitoring and integration into smart home systems.
10. Compact and Durable Design: The inverter features a compact design with dimensions of 420×670×233 mm (excluding connectors and brackets) and weighs 30kg. Its IP65 rating ensures it is protected against dust and water ingress, enhancing its durability and suitability for outdoor installations. The intelligent air-cooling system further ensures optimal operating temperatures and longevity.

Specifications:
