Giada F108D N100 Mini PC, Intel N100 3.40GHz, No RAM, No SSD, Intel HD Graphics, No OS

Overview:

GIADA F108D N100 1X DDR4 3200MHZ 2X HDMI
The Giada F108D Signage Player adopts Intel Alder Lake-N processors, giving you good performance while featuring a low-power range from 6-15W. The book-size embedded PC is specially designed for digital signage and kiosk applications. The slim embedded PC supports rich I/O ports, including dual COM ports, 6 USB Type-A and dual LAN ports. It can also be easily integrated into vending machines, self-service and check-in kiosks. The digital signage player also comes with built-in Intel UHD Graphics. It has a DP and two HDMI ports, supporting resolutions up to 4096 x 2160@60Hz. With a passive thermal cooling system, the fanless design reduces the failure rate and makes the device run noise-free and dustproof.

Features:

• Intel Processor N100
• DDR4 3200MHz memory support
• Intel UHD onboard graphics
• Up to 4k resolution support
• 1x DP and 2x HDMI output
• Support for Wi-Fi/Bluetooth module
• Small form factor design

WHATS IN THE BOX:

• Giada F108D Alder Lake-N Book Size Signage Player - Black x1

Specifications:

Product Code	F108D-FV-N10040N0G-GIA
CPU	Intel Processor N100 (Fanless)
Turbo Frequency	3.40GHz
Chipset	SoC
Processing Units	4 Cores
TDP	6W
System Memory	Up to 16 GB, 1 x SO-DIMM DDR4-3200 MHz
Storage	1 x M-Key M.2 (2280) for PCIe3.0 X4 SSD
Watchdog Timer	Yes
Auto Power On	Yes
RTC	Set up independently every day, a week as a cycle
Remo on	No
Power Requirement	DC-IN, 19 V/2.37 A
Construction	Metal
Operating System	Windows 11 (64bit) /Linux Ubuntu (64bit)
Operating Temperature	0°C ~45°C (32°F~113°F) @0.7m/s Air Flow
Certifications	CE, FCC Class B, UKCA
Humidity	95% @ 45°C (non-condensing
Network Controller	2 x Realtek RTL 8111H Gigabit Ethernet
Ethernet Interface	2 x RJ45
Wi-Fi/BT	1 x E-Key M.2 (2230) for Wi-Fi/BT, Support Wi-Fi 5, Wi-Fi 6
Mobile Network	1 x B-Key M.2 (3042) for 3G/4G, 1 x SIM Slot
GPU	Intel UHD Graphics
Graphic Engine	DirectX 12.1, OpenGL 4.6, OpenCL 3.0
Display Interface	1 x DP (Max.4096 x 2160 @60Hz), 2 x HDMI (Max.4096 x 2160 @60Hz)
USB	2 x USB3.2 Gen2, 4 x USB2.0
Serial Port	2 x RS232
Audio	1 x MIC-IN, 1 x AUDIO-OUT
Button	1 x Power on, 1 x CLR-CMOS
Antenna	2 x Connector for Wi-Fi/BT
Product Dimensions	18.9 x 14.8 x 2.6 cm
