- Pure sine wave output
- 2000 cycles lifePO4 battery
- Mains supply mode, Battery mode
- 5V DC USB 2.0 ports
- 12V DC output ports
- MPPT solar charge controller
- Over charge protection as well as over discharge protection
- Intelligent exhaust fan
Specifications:
| Product Code | SOL-I-BB-M2L
|
| Inverter Specifications | |
| Rated Power | 2 000VA / 2 000W |
| INPUT | |
| Voltage range | 170 - 275V |
| Mains charging current | 10A |
| Frequency Range | 45-65Hz |
| OUTPUT | |
| Voltage | 230V AC |
| Frequency | 50/60Hz |
| Output wave form | Pure Sine Wave |
| BATTERY | |
| Battery Voltage | 25.6V DC |
| Battery capacity | 1X 100Ah |
| Battery cycle life | 2 000 Cycles @ DOD 80% |
| SOLAR CHARGER | |
| Solar Charger Type | MPPT |
| Maximum PV Array Power | 840W |
| Number of MPPTs | 1 |
| MPPT Range @ Operating Voltage | 35 - 100V DC |
| Maximum Solar Current Charger | 30A (Max) |
| Floating Charge Voltage | 28.4V DC |
| DC OUTPUT | |
| Low Voltage recovery | 26.8V DC |
| Low Voltage Protection | 22.4V DC |
| 5V DC USB Output | 2 Pcs 5V DC, USB 2.0, Max 2A |
| 12V DC Output Ports | 2 Pcs Max 2A |
| PHYSICAL | |
| Heat Dissipation / Cooling | Intelligent exhaust fan (Temperature controlled) |
| Dimensions | W x D x H (mm): 480 X 192 X 410 |
| Packing size | W x D x H (mm): 527 X 277 X 475 |
| Net Weight (kgs) | 45kg |
| Gross Weight (kgs) | 48kg |
