Tenda AX3000 DB Gigabit WI-FI 6 Router

Tenda AX3000 DB Gigabit WI-FI 6 Router

Premium Wi-Fi 6 Performance for Your Smart Home Members
AX3000 for Ultra-Fast Transmission Speed

RX9 Pro is a Dual-band Wi-Fi 6 Tenda router that provides 160MHz bandwidth and 1024-QAM for ultra-fast wireless connection. With a total networking speed of 2976Mbps — 574Mbps on the 2.4GHz band and 2402Mbps on the 5GHz band.

Minimize Lag for a Better, Smart Products Experience

ith the innovative combination of OFDMA + MU-MIMO, 802.11ax technology provides greater network capacity and efficiency in congested environments than Wi-Fi 5.
OFDMA divides each channel into small sub-channels, allowing signals from multiple appliances to be bundled together and transmitted simultaneously, reducing latency for a smoother Wi-Fi experience.

1.6GHz Dual-Core Processor Provides Faster and More Stable Wi-Fi Experiences

Equipped with a 1.6GHz high-performance Dual-core processor, the operating capacity reaches up to 3000 DMIPS, and NPU processing speed reaches 2220 MHZ, which improves network load capacity, responds faster, and is more stable.

" Four Plus Four " Makes Full Wi-Fi Coverage

Four FEM Modules with the independent signal amplification work with four 6dBi external omnidirectional dual-band antennas for wider Wi-Fi coverage.

BSS Coloring Reduces Interference and Improves Efficiency

Supporting BSS colouring technology, RX9 Pro effectively alleviates co-frequency interference, improves spectrum utilization and communication efficiency.

IPv6 Supported

Compared with IPv4 protocol, IPv6 has a large number of IP addresses. Unordered Internet access through address translation can shorten the data transmission time between Internet devices and servers.

TWT Extends Battery Life of Connected Devices

TWT (Target Wake-up Time technology) can effectively reduce the power consumption of terminal equipment and greatly extend its battery life.

The Next-Gen Security Protocol WPA3

The RX9 Pro carries a new generation of Wi-Fi security standard WPA3, which increases the difficulty of algorithmic and network password cracking to prevent forced attacks, violent cracking.

Remote Control Through the Tenda APP

Wi-Fi status can be controlled remotely through the Tenda APP, even while travelling, which facilitates the real-time monitoring of the home network

Specification

Hardware

Standard&Protocol
IEEE802.3, IEEE802.3u,IEEE802.3ab

Interfaces
1*10/100/1000Mbps WAN port
3*10/100/1000Mbps LAN ports

Antenna
4*6dBi external antennas

Button
1* WPS/Reset button

Power
Input： AC 100-240V~50/60Hz 0.6A
Output： DC 12V⎓1.5A

Dimension
272.44x162.85x43.71mm

LED Indicator
SYS*1

Wireless

Wireless Standard
IEEE 802.11ac/a/n/ax 5GHz
IEEE 802.11b/g/n/ax 2.4GHz

Data Rate
5GHz: Up to 2402Mbps
2.4GHz: Up to 574Mbps

Frequency
Simultaneous dual-band 2.4
Transmission Power

CE:
<20dBm(2.4G)
<23dBm(5G)

Basic Features
SSID Broadcast: Enable/Disable
Transmission Power: high, medium, low

Wireless Security
WPA-PSK,WPA2-PSK, WPA/WPA2-PSK
WPA3-SAE/WPA2-PSK
Wireless Security: Enable/Disable
WPS (WiFi Protected Set-up) fast encryption

Software

Internet Connection Type
PPPoE, Dynamic IP, Static IP

Operating Mode
Wireless Router Mode

AP Mode
DHCP Server
DHCP Server
DHCP Client List
DHCP Reservation
Virtual Server
Port Forwarding
DMZ Host
UPnP

Security
Client Filter
Parental Control(support black list and white list)
Remote Web Management

Firewall
Forbid UDP flood attack
Forbid TCP flood attack
Forbid ICMP attack
Forbid WAN PING from the internet

DDNS
no-IP,Oray, 88ip,DynDNS

VPN
PPTP server
PPTP client
L2TP client

Special Features
Smart Traffic Prioritisation
PPPoE Username/password Clone
Smart WiFi Schedule
Smart LED on/off
Tenda Cloud
Tenda App

Others
Bandwidth Control
Guest Network
IPTV
VLAN
MAC Clone
Static Routing
System Log
Backup

Others

Temperature
Operating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~ 70℃.

Humidity
Operating Humidity:10% ~ 90% RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing.

Certification
CE/FCC/RoHS
EIRP Power (Max)
2.400-2.4835GHz:19.95dBm (EIRP)
5.150-5.250GHz:22.98dBm (EIRP)

Package Contents
Wireless Router x1
Power Adapter x1
Install Guide x1
Ethernet Cable x1
