TP-Link TL-WR840N 300Mbps Wireless N Speed Router - Broadcom, 2T2R, 2.4GHz, 802.11n/g/b, Built-In 4-Port Switch, Internal Antenna

Features:

• 300Mbps wireless transmission rate ideal for both bandwidth sensitive tasks and basic work
• Supports 4 modes: Router, Range Extender, Access Point and WISP modes
• Parental Controls manage when and how connected devices can access the internet
• IPTV supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming
• compatible with IPv6 (Internet Protocol version 6)
• Guest Network provides separate access for guests while securing the home network

300Mbps Wireless N Speed - Fast Download Speed
TL-WR840N is compatible with IEE 802.11b/g/n and provides a high speed solution. Complying with the IEEE802.11n standard, TL-WR840N can deliver a speed up to 300Mbps, meeting your most demanding home networking needs, such as HD streaming, online gaming and large files downloading.

Easy Parental Control
Parental Control allows parents or administrators to deploy restricted access for children or staff. With URL blocking, you can easily set up a black or white list to limit the level of web access.

Guest Network Access
Guest Network function provides secure access for guests to sharing your Wi-Fi network. Easy sharing, no worry about your private network.

Easy Setup and Use
Set up the TL-WR840N in minutes thanks to its intuitive web interface and the powerful Tether app. Tether also lets you manage its network settings from any Android or iOS device, including parental controls and access control.

Specifications:

Product Code	TL-WR840N
WIRELESS
Standards	Wi-Fi 4
	IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds	N300
	2.4 GHz: 300 Mbps (802.11n)
WiFi Range	2 Bedroom Houses
	2x Fixed Antennas
WiFi Capacity	Legacy
Working Modes	Router Mode
	Access Point Mode
	Range Extender Mode
	WISP Mode
HARDWARE
Processor	Single-Core CPU
Ethernet Ports	1x 10/100 Mbps WAN Port
	4x 10/100 Mbps LAN Ports
Buttons	Reset Button
Power	9 V ~ 0.6 A
SECURITY
WiFi Encryption	WEP
	WPA
	WPA2
	WPA/WPA2-Enterprise (802.1x)
Network Security	SPI Firewall
	Access Control
	IP & MAC Binding
	Application Layer Gateway
Guest Network	1x 2.4 GHz Guest Network
SOFTWARE
Protocols	IPv4
	IPv6
Parental Controls	URL Filtering
	Time Controls
WAN Types	Dynamic IP
	Static IP
	PPPoE
	PPTP
	L2TP
Quality of Service	QoS by Device
NAT Forwarding	Port Forwarding
	Port Triggering
	DMZ
	UPnP
IPTV	IGMP Proxy
	IGMP Snooping
DHCP	Address Reservation
	DHCP Client List
	Server
DDNS	NO-IP
	Comex
	DynDNS
Management	Tether App
	Webpage
OTHER
System Requirements	Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
	Cable or DSL Modem (if needed)
	Subscription with an internet service provider (for internet access)
Certifications	FCC, CE, RoHS
Environment	Operating Temperature: 0°C~40°C (32°F ~104°F)
	Storage Temperature: -40°C~70°C (-40°F ~158°F)
	Operating Humidity: 10%~90% non-condensing
	Storage Humidity: 5%~90% non-condensing
TEST DATA
WiFi Transmission Power	CE:
	<20dBm(2.4GHz)
	FCC:
	<30dBm
WiFi Reception Sensitivity	270M: -68dBm@10% PER
	130M: -68dBm@10% PER
	108M: -68dBm@10% PER
	54M: -68dBm@10% PER
	11M: -85dBm@8% PER
	6M: -88dBm@10% PER
	1M: -90dBm@8% PER
PHYSICAL
Dimensions (WxDxH)	7.2 x 5.0 x 1.4 in
	(182 x 128 x 35 mm)
Package Contents	Wi-Fi Router TL-WR840N
	Power Adapter
	RJ45 Ethernet Cable
	Quick Installation Guide
